| 产品及产能 | 5L单腔（推板） |
| 制品容积（ML）Max.Volume of product(ML) | 1500-5000 |
| 制品最大高度（MM）Max.Height of Product(MM) | 330 |
| 适合胚管壁厚（MM）Wall Thickness of Preform (MM) | 1-4 |
| 适合胚管壁厚（MM）Wall Thickness of Preform (MM) | 180 |
| 制品最大直径（MM）Max.Diameter of Product(MM) | φ170 |
| 生产能力（瓶/小时）Production Capacity (PCS/HR) | 500-600 |
| 胚管加热装置 HEATING DEVICE |
| 胚管座数（个）Mo.of Preform Holder(PCS) | 58 |
| 适合胚管口内径（MM）Max.Neck Diameter of Preform | φ20-35 |
| 远红外线光管排列(支×区) Arrangement of Infra-Red Tubes(PCSxZONES) | 8×9 |
| 实际加热功率(KW) Average Power Consumption(KW) | 20-24 |
| 拉吹装置 STRETCH-BLOW DEVICE |
| 模具腔数No.of Mould Cavity | 1 |
| 模具标准厚度(MM) Standard Mould Thickness(MM) | 260±0.1 |
| 模具标准宽度(MM) Standard Mould Width(MM) | 220±0.1 |
| 开模最大行程MM) Max.Span Between Opening Moulds(MM) | 230 |
| 模腔标准间距Standard Span Between Mould Cavities(MM) | |
| 额定动作气压(Mpa) Working Air Pressure(Mpa) | 0.8～1 |
| 最大吹气气压(Mpa) Blowing Air Pressure(Mpa) | 3 |
| 要求空压机排气量(M3/MIN)（低压/高压）Volume of Low/High Pressure Air Compressor(M3/MIN) | 1.2/2 |
| 机台外型尺长×宽×高（MM）Dimensions(Length×Width×Height)(MM) | 2720×1200×1600 |
| 主机重量（KG）Weight | 2500 |
